The VHF Citrine is a 25 MHz to 160 MHz fixed frequency rugged OCXO featuring Standard, Premium or Golden phase noise options (to -190 dBc/Hz), good temperature stability and low g-sensitivity (to 2E-10/g per axis). Designed for demanding applications, the VHF Citrine provides excellent phase noise performance under vibration with both hard-mount and a vibration isolated version available. The hard-mount nickel-plated machined aluminum package is 2” x 2” x 0.7” with single and dual output options. A low noise internal voltage regulator is included, which provides excellent power supply line rejection. Please consult the factory to discuss any custom specification modifications which may better suit your application.
Frequencies from 25 MHz to 160 MHz, fixed
Standard Premium and Golden Phase Noise Options
Ruggedized for Dynamic Environments
Nickel-Plated Machined Aluminum Case
SMA(f) and Solder Pins on Side
Optional Voltage Reference and Oven Monitor Pins
Output: Sine, +13 dBm, Standard; To +18 dBm, Optional
Low G-Sensitivity 2E-12/g per axis
Dual Output Version Available
Excellent Temperature Stability
Phase Lock Option Available
Vibration Isolated Version Available
Vibration Isolated Version Available
Airborne, Ground, Shipboard
AESA RADAR Systems
Military Applications
Tactical Radio
Vehicular Communications
Reference Source
