The HF Citrine Plus is a 10 MHz to 25 MHz fixed frequency rugged OCXO coupled with an additional circuit such as a multiplier, divider, amplifier or filter, when the application demands something extra. The integrated unit can provide output frequencies from 5 MHz to 125 MHz and offers excellent aging and temperature stability, Standard or Premium phase noise and low g-sensitivity (to 1E-10/g per axis). Designed for demanding applications, the HF Citrine Plus provides excellent phase noise performance under vibration with both hard mount and a vibration isolated version available. The hard mount nickel-plated machined aluminum package is 2.25” x 2.25” x 1.3”. An internal voltage regulator is provided for excellent power supply line rejection. Please consult the factory if you need any specifications to be modified to better suit your application.
Frequencies from 5 MHz to 125 MHz, fixed
Standard and Premium Phase Noise Options
HF OCXO (5 MHz to 25 MHz) Plus an Additional Circuit
Option to add Multiplier, Divider, Filter, PLL or Amplifier
Ruggedized for Dynamic Environments
Nickel-Plated Machined Aluminum Case
SMA(f) and Solder Pins on Side
Optional Voltage Reference and Oven Monitor Pins
Output: Sine, +13 dBm, Standard; To +21 dBm (w/Integrated Amplifier)
Low G-Sensitivity to 1E-10/g per axis
Excellent Temperature Stability
Low Aging rate
Vibration Isolated Version Available
Airborne
Radar Systems
Tacticle Radio
Vehicular Communication
